ED Tower UPS
The Falcon® Electric ED Series Rackmount UPS and Frequency Converter provides clean, precision-regulated AC power from 47Hz–450Hz input, delivering unmatched reliability and protection for mission-critical industrial, military, and laboratory environments.
Products
ED Tower UPS
If there is a description it goes here. Otherwise this should be deleted.
ED-1000-1
ED-1500-1
ED-2000-1
ED-2400-1
ED Tower Voltage Regulator
If there is a description it goes here. Otherwise this should be deleted.
- ED-1000-A
- ED-1500-A
- ED-2000-A
- ED-2400-A
- ED-3000-A
- ED-4000-A
- ED-5000-A
ED Tower Voltage & Frequency Converters
If there is a description it goes here. Otherwise this should be deleted.
- ED-1000-1/2LC
- ED-1000-2/1LC
- ED-1500-1/2LC
- ED-1500-2/1LC
- ED-2000-1/2LC
- ED-2000-2/1LC
- ED-2500-1/2LC
- ED-2400-2/1LC
Key Features
Topology & Output
Regenerative true double-conversion; pure sine output (<3% THD); 1 ms recovery; starts high-inrush loads.
Output Choices
Fixed 50/60Hz; accepts 47–450Hz input; optional 400Hz output; 120↔230Vac conversion.
Input & Efficiency
120/230Vac models; wide frequency; brownouts to 88Vac; optional PFC.
Batteries & Runtime
Optional sealed VRLA packs add UPS backup; scalable runtime.
Monitoring & Comms
Front-panel LEDs and audible alarms; dry-contact (DB-9) status (utility loss/low battery/alarms).
Agency Approvals
UL-listed models; note temperature limits; consult factory for UL/CE/FCC.
Operating Environment
0–50°C typical; -20–50°C rackmount; 10–95% RH; 7–10k ft; 49–60 dBA.
Form Factor
4U, 19″ rackmount chassis and compact tower options; lightweight, small-footprint designs.
Applications
Falcon’s ED Tower UPS can be found in non-milgrade equipment in these types of environment
Military Surveillance Center
Climate-Controlled Server Rooms
Training Facilities
Military R&D Lab
Non Milgrade Equipment
- Additive manufacturing/3D printers
- Badge server
- Battery charging banks
- Calibration equipment/labs
- Imaging/diagnostics equipment
- Routers/switches
- Servers
- Storage arrays
- Tool-control PCs
- Video walls/displays
- Video-conferencing bridges
- VoIP systems
- Workstations
Need a custom solution?
Tell us about your project and we can design a UPS that fits your needs?
