Falcon’s SSG-RP-H is an extreme temperature UPS, true online industrial UPS operating from −40°C to +70°C. It delivers clean 120 Vac, zero-transfer power, and a wide 80–138 Vac input window. Hot-swappable, wide-temp VRLA packs and optional banks extend runtime from ~12.5/29 minutes to ~98/200 minutes. Ruggedized build and USB/RS-232, optional secure SNMP/HTTP, relays, REPO, and MB2K-1 maintenance bypass simplify integration and maintenance, making it a reliable industrial power supply solution for extreme environments.
Operates/storage −40°C to +70°C with 80–138 Vac input window and zero-transfer output in an extreme temperature UPS environment.
Flexible Run time
Hot-swappable wide-temp VRLA; 1.5 kVA: 12.5/29 min as shipped, up to 98/200 min with four banks; 40Ah option for multi-hour backup in an extreme temperature UPS setup.
True On-line Industrial Design
Zero transfer time, tight ±2% regulation, sinewave output, PFC input, IEEE surge suppression, ruggedized build (conformal-coated boards, encapsulated fans).
10-year-rated, maintenance-free batteries, user-replaceable/hot-swappable packs, and remote monitoring to reduce site visits in extreme temperature UPS deployments.
SSG-RP-H Rackmount Extreme Temperature UPS
Feature
Standard UPS
SSG-RP-H (Extreme Temperature UPS)
SSG-RP (Ultra-wide Temp)
SSG (Wide-temp)
Operating Temperature Range
Commonly -20°C to +50°C (often needs enclosure heaters/coolers to sustain extremes); ranges vary by model.
-40°C to +70°C
-30°C to +65°C
-20°C to +55°C
UPS Design
Standby or line interactive topologies provide minimal level of protection against power problems. Not designed for critical applications.
True on-line (double-conversion) industrial
True on-line (double-conversion) industrial
True on-line (double-conversion) industrial
Battery Life
Typical VRLA ~3–5 years at 25°C; elevated temps shorten life significantly.
10-year at 25°C (extreme-temp VRLA)
10-year at 25°C
12-year at 25°C (≈4-year at 50°C)
Battery Runtime
Often limited to internal packs; some models allow add-on banks, but expansion depth and documentation vary.
1.5 kVA: 12.5 / 29 min (full/half); up to 98 / 200 min with four ext. banks
1.5 kVA: 12.5 / 28 min; up to 100 / 200 min with four ext. banks
Usually USB or RS-232 and sometimes SNMP; outdoor NEMA enclosures available on select lines; industrial I/O (dry contacts, REPO, maintenance bypass) not always standard.
Introduction Many people associate uninterruptible power supply (UPS) usage as a device in an environmentally-controlled location, quietly ready to protect against any power problems. Yet, using a UPS in an
Falcon Electric’s UPSilon software is now available for users to download from our website. UPSilon software is compatible with all Falcon UPS models.* If you have any technical questions, email
We receive many questions about the available options on our field-proven, reliable SSG and SSG-RP Industrial and Outdoor UPS Systems. (-20°C to 50°C and -30°C to 65°C; 1 to 6kVA).
Facilities with automation, robotics, and heavy machinery.
Networks delivering voice, data, and internet services.
Railways, airports, tolling stations, and control systems.
