FN2 UPS
Protect servers and network gear with Falcon FN2 true online UPS delivering unity power factor and zero-transfer switching. Isolated 120/208V selectable output, 50/60Hz fixed or tracking; wide input with 0.99 PFC; hot-swappable expandable batteries; LCD plus USB/RS-232 and optional SNMP/HTTP; scalable N+1 parallel to 40 kVA.
Products
FN2 Rackmount UPS
If there is a description it goes here. Otherwise this should be deleted.
- FN2-4.5KRM-2TXI
- FN2-6KRM-2TXI
- FN2-8KRM-2TXI
- FN2-10KRM-2TXI
FN2 Tower UPS
If there is a description it goes here. Otherwise this should be deleted.
- FN2-4.5K-2TXI
- FN2-6K-2TXI
- FN2-8K-2TXI
- FN2-10K-2TXI
Key Features
Topology & Output
True on-line (0 ms transfer), unity PF (kW = kVA)
Output Choices
Isolated output; selectable 120/208, 110/220, 115/230, 120/240 Vac; 50/60 Hz auto or fixed
Input & Efficiency
Wide input window; PFC 0.99; up to ~94–95% ECO-mode efficiency
Batteries & Runtime
Hot-swappable VRLA; expandable external banks for minutes-to-hours runtime
Monitoring & Comms
LCD, USB, RS-232; optional SNMP/HTTP; REPO; optional PDU/MBS
Agency Approvals
UL1778, cUL, FCC Class A, CE
Operating Environment
0–40 °C, <60 dBA, 20–95% RH (non-condensing)
Form Factor
Rackmount chassis (separate inverter/transformer/battery modules)
Compare a Standard UPS to a Falcon SSG UPS
Battery Options & Chargers
Battery Options
FN2 Rackmount VRLA
FN2-BRM-1S9
FN2 Tower VRLA
FN2-BT-3S9
Battery Chargers
FN2 Rackmount & Tower Model Charger
CHG 1000W-240V
Applications
Falcon’s UPS can be found in various types of Data Centers.
Accessories & peripherals
Communications
UPS Remote Management Card Compatible with SC and FN2 UPS Models
Power Distribution
FN2-PDU208-240/MBS
FN2-PDU208-240
FN2-PDU208-240/120
Need a custom solution?
Tell us about your project and we can design a UPS that fits your needs?
Case Studies
Johnson Controls
Johnson Controls chooses Falcon Electric for power protection needs at Ft. Lauderdale/Hollywood International Airport.
KK Electronic
Falcon High-Temperature UPS helps wind turbine handle extreme conditions.
Edwards AFB
C-130 Hercules powers-up with Falcon Electric’s innovative frequency converter.
